Premium Casters – 2 Rigid, 2 Swivel with face Contact BrakeStandard corner and center captures for retainment4000 lbs Capacity Standard Ergo push handleExtreme Low MaintenanceThe Flatbed Tugger Cart – 66″ x 50″ RAFF-6650-40 (Rider, “A” Size, Flatbed, Full Deck) is part of our CarryMore mother-daughter cart system. This daughter cart features standard corner and center captures designed around the 45″ x 48″ knock down container or standard pallets for secure load retainment. The cart rides on premium poly casters with 2 rigid, 2 swivel casters with the alumilock face contact brake for better steering control.
This cart is protected with powder-coat paint available in multiple standard colors. It can carry up to 4000 lbs and works with any of the “A” size mother carts. The ergo handle has a bend to keep operators’ hands away from the load and is at the optimum height of 42″ from the ground. The CarryMore system increases safety, productivity, and reduces cost.
For more information, contact us today.
Need More Information? Have Us Contact You
The RAFF-6650-40 provides a full flat deck for transporting pallets, knock-down containers, and other compatible loads within Jtec’s CarryMore mother-daughter cart system. Its standard captures are designed around 45″ x 48″ knock-down containers and standard pallets. Other loads should be evaluated for size, weight, stability, and retention requirements.
The cart can carry loads weighing up to 4,000 lbs. This capacity applies to the complete load placed on the deck. Load dimensions, weight distribution, center of gravity, and required retention should also be considered when determining whether the cart fits a specific material-handling application.
Standard corner and center captures help retain compatible pallets and containers on the full deck during transport. These captures are designed around 45″ x 48″ knock-down containers and standard pallets. Loads with different footprints or base constructions may require a separate review to determine the appropriate retention method.
The cart rides on premium poly casters in a two-rigid and two-swivel configuration. The swivel casters include Alumilock face contact brakes for braking and steering control. The suitability of this configuration depends on the load, route, travel frequency, floor condition, and required manual maneuverability within your facility.
The standard ergonomic push handle is positioned 42″ from the ground. It includes a bend designed to keep the operator’s hands away from the load while manually maneuvering or positioning the cart. The load should still be arranged so it does not interfere with the handle area or the operator’s visibility.
The RAFF-6650-40 is an A-size daughter cart and works with any A-size CarryMore mother cart. Listed compatible configurations include Outdoor, Quad Steer, Electric Lift, Dual Bay, and Center Steer mother carts. The appropriate configuration depends on your load, route, floor conditions, tow vehicle, and delivery process.
