Rotating Deck with 180° stopsPremium Casters – 2 Rigid, 2 Swivel with face Contact BrakeStandard corner and center captures for retainment2500 lb Capacity Standard Ergo push handleThe Turn Table Cart – 50″ x 50″ RATT-5050-25 (Rider, “A” Size, Turn, Table) is part of our CarryMore mother-daughter cart system. This daughter cart features a 50″ x 50″ rotating deck with stops every 180 °. The rotation is activated by a foot pedal release located opposite the handle side. Standard corner and center captures are designed around the 45″ x 48″ knock-down container or standard pallets for secure load retainment. The cart rides on premium poly casters with 2 rigid, 2 swivel casters with the alumilock face contact brake for better steering control.
This cart is protected with powder-coat paint available in multiple standard colors. It can carry up to 2,500 lbs and works with any of the “A” size mother carts. The ergo handle has a bend to keep operators’ hands away from the load and is at the optimum height of 40” from the ground. The CarryMore system increases safety, productivity, and reduces cost.
For more information, contact us today.
Need More Information? Have Us Contact You
The RATT-5050-25 can carry loads weighing up to 2,500 lbs. Its 50″ x 50″ deck is designed for transporting containers or pallets within a CarryMore mother-daughter cart system. The total load must remain within the stated capacity and be properly retained during movement.
The deck rotates after the operator activates a foot-pedal release located opposite the handle side. It includes stops every 180°, allowing the load to be repositioned so operators can access the opposite side without turning the entire cart. This can support more efficient loading, unloading, and lineside material presentation.
The cart’s standard corner and center captures are designed around 45″ x 48″ knock-down containers and standard pallets. These captures help retain the load on the rotating deck during transport. The suitability of other load sizes or container styles should be confirmed based on their dimensions, weight, and required points of retention.
The RATT-5050-25 works with any A-size CarryMore mother cart. The product page identifies compatible configurations including Outdoor, Quad Steer, Electric Lift, Dual Bay, and Center Steer mother carts. The correct mother cart depends on your route, tow vehicle, load requirements, floor conditions, and preferred material-delivery process.
The cart uses premium poly casters in a two-rigid and two-swivel configuration. The swivel casters include Alumilock face contact brakes, providing braking capability and better steering control during manual movement and positioning. Facility floor conditions, travel distance, load weight, and operating environment should be considered when confirming the cart configuration.
